VACUUM OVEN, 9.3 CU FT, 230V

Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare

$34,979.00

SKU: SVAC9-2 Categories: , Tag:
The SHEL LAB Model SVAC9-2 is one of the largest vacuum ovens on the market, with 9.3 cubic feet of capacity. This unit also features a fully programmable Watlow controller and a cool touch surface. A digital vacuum gauge shows chamber vacuum level in measurements of Torr and m/Torr. The display range is 760 Torr down to 0 mTorr (Maximum permitted end vacuum is 10 mTorr. Leak rate is 30 mTorr in 30 min). A secondary independent high limit controller provides overtemperature safety protection.

This unit includes true vacuum valves and has cross-flow ventilation within the oven chamber to enhance total performance. The vacuum oven is secured to a ruggedly constructed mobile stand to create a vacuum pump at the base. Although the oven is not supplied with a vacuum pump, all vacuum plumbing and KF25 connections are provided.

The SHEL LAB SVAC9-2 vacuum oven is equipped with a Viton gasket, which provides an excellent combination of high-temperature performance and chemical resistance. When paired with this oven’s deep-draw capacity and large chamber volume, the SVAC9-2 serves as one of the most robust vacuum work stations available on the market.

Features include:

  • Watlow Controller Capable Of 40 Step Ramp And Soak Profiles, Or 4 Files With 10 Steps Per File
  • Stainless Steel Interior
  • Stainless Steel Exterior Option Available (Ideal For Cleanroom Applications)
  • KF25 Fitting Included
  • Built in Vacuum Pump Mount
  • 24 Month Limited Warranty
Ask us about our Extended Warranties!

Specification: VACUUM OVEN, 9.3 CU FT, 230V

Weight 492 lbs
