USA Lab 50L 200°C 9KW or 6KW Closed Loop Heater CRH-50L 15L/min

Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare
6KW Power Requirements: 220-240V 50-60hz 28A Single Phase 6-30P Plug
9KW Power Requirements: 220-240V 50-60hz 42A Single Phase – Hard wire ONLY
Temperature Range: RT to 200°C
Tank Capacity: 35L
Circulating Pump Wattage: 250W
Temperature Accuracy: +/- 1°C
Pump Flow & Lift: 35L/Min & 25m
Inlet / Outlet Size: 3/4″ MNPT
External Dimensions: 28″ x 19.7″ x 43.3″
Weight: 155lbs
Warranty: 1 Year

$7,798.00$8,398.00

SKU: CRH-50L Category: Brand:

The USA Lab CRH heater is a powerful 200°C heater with a 35L expansion tank. Our CRH heater comes with a high powered stainless steel heater, and a strong pump for constant flow and high performance. The closed loop system allows for higher thermal transfer performance than open loop heaters, and provides superior heating capabilities. This unit is a true lab heater that is ideal for applications involving vacuum systems, jacketed reactors, columns, solvent tanks, and even analytical instruments. This system is great for larger columns, tanks, and high heat applications.

The USA Lab CRH heater offers unbeatable performance, ease of use and high reliability. These closed loop heaters are the best on the market for demanding applications and precision heating.



CRH-50 FEATURES

• Powerful high wattage heating up to 200°C.

• Easy to read LCD digital display.

• Stainless steel heating elements.

• Strong oil pump.

• 12ft of insulated tubing included.

• 1 Year warranty with US based parts and support.

• Closed loop for higher thermal transfer performance.







SPECIFICATIONS

Model

CRH-50 6KW

CRH-50 9KW

Expansion Tank Capacity

35L

Oil Tank Dimensions

450 x 300 x 200mm

Temperature Range

RT to 200°C

Power Requirements

220-240V 50-60hz 28A Single Phase L6-30 Plug

220-240V 50-60hz 42A Single Phase – Hardwire ONLY

Control Type

LCD Digital Display

 Heating BTUs / Wattage

20472 BTU / 6000W

30709 BTU / 9000W

Total Power

6250W / 28A

9250W / 42A

Circulating Pump Wattage

250W

Temperature Accuracy

+/- 1°C

Pump Flow

35L/Min

Lift

25m

Inlet / Outlet Size

3/4″ MNPT

External Dimensions

28″ x 19.7″ x 43.3″

Weight

155lbs

Warranty

1 Year







PACKING LIST

Model

Quantity

USA Lab CRH-50 Heater

1

3/4″ FNPT Insulating Tubing – 6ft

2

 Manual

1





For Technical Support, Questions, or Other Issues Please Email or Call Us!
