HFS(R) 6” Material Spool Vessel, Complete, Ready to use

Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare

$1,122.40$1,237.40

SKU: N/A Category: Brand:

Standard  Material Column includes:
Intake Manifold
Hemispheric End Caps
Tri Clamp Spool
Filter Plate
Retaining Ring
Stackable Ring and Plate Set
High Pressure Clamps
Viton Gaskets
Mesh Screen Viton Gaskets, 100 Mesh (150 um) + 40 Mesh (420 um)
Evacuation Port

SKU:CLS-6×6-ST

Features: Material Column
Material: Stainless Steel
Wall Density (MM): 3
Max Temp. (F): 250
Max Pressure (PSI): 100
Connection Type: MJIC
Specifications: Material Column
Diameter (IN): 6
Height (IN): 6
Radius (IN): 3
Volume (Cu In): 169.56
SKU:CLS-6×12-ST
Features: Material Column
Material: Stainless Steel
Wall Density (MM): 3
Max Temp. (F): 250
Max Pressure (PSI): 100
Connection Type: MJIC
Specifications: Material Column
Diameter (IN): 6
Height (IN): 12
Radius (IN): 3
Volume (Cu In): 339.12

SKU:CLS-6×24-ST
Features: Material Column
Material: Stainless Steel
Wall Density (MM): 3
Max Temp. (F): 250
Max Pressure (PSI): 100
Connection Type: MJIC
Specifications: Material Column
Diameter (IN): 6
Height (IN): 24
Radius (IN): 3
Volume (Cu In): 678.24
SKU:CLS-6×36-ST
Features: Material Column
Material: Stainless Steel
Wall Density (MM): 3
Max Temp. (F): 250
Max Pressure (PSI): 100
Connection Type: MJIC
Specifications: Material Column
Diameter (IN): 6
Height (IN): 36
Radius (IN): 3
Volume (Cu In): 1017.36

Product Enquiry
