1.9CF ECO Vacuum Oven and VE Series Pump Kit

Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare



1.9CF ECO Vacuum Oven and VE Series Pump Kit

DISCLAIMER: This unit is intended for LEGAL purposes only, to be used in accordance with local laws and ordinances. Use only in WELL VENTILATED AREAS!

1.9CF ECO Vacuum Oven – LED – 5 Shelves Standard
Backed with our 2 Year Parts and Labor warranty

Our ovens offer:

  • The guaranteed industry standards ability to lose less than 1” Hg over a 24 hour period.
  • Reliable deep vacuum that reaches below 0.1 torr. with stainless steel compression-fit tubing and stainless steel instrumentation valves.
  • Uniform heat which is key to an effective oven. Our ovens offer 7% temperature uniformity across all shelves with offering ±1⁰ stability in temperature.
  • Comes standard with the maximum number of shelves and a well-lit LED interior.
  • Items Included: 5′ 37⁰ female flared HVAC hose; USA power cord; and oven operation manual. You’ll get the complete package only with Best Value Vacs.

Key Oven Features:

  • 1/4″ JIC Vacuum Port with included 5′ HVAC Hose
  • Easy Vac-Release Dial allows release of vacuum without disconnecting pump or purge
  • Stainless steel interior for a sanitary, easy-to-clean look
  • Overload circuit breaker for electrical protection
  • Comes standard with 5 shelves


Electrical 120 VAC / 60Hz / 800W / USA Plug
Internal Chamber Four Wall Heating
Material: Polished Stainless Steel
Dimensions (LxWxH): 14-1/4″ x 16-1/2″ x 13-3/4″
Temperature Control LED PID Controller
Temperature Range: Room Temperature – 212⁰F
Temperature Stability: ± 1.8⁰F or ± 1⁰C
Automatic Over Shoot Shut Down
Over Temp Alarm
Vacuum Gauge Ranging from -1inHG to -30inHG
Maximum Vacuum Level -29.9” Hg / -75.4 cmHg / -1 MPa /
Shelves Up to 8 sliding shelves at one time
Reinforced steel with sides to secure product
Shelf Capacity (area): 129 in2
Total Shelf Capacity: 1035 in2 or 7.2 ft2
Dimensions (LxW): 11-3/8″ x 11-3/16″
Door ½” Tempered Glass window with LEDs
Window Dimensions (LxH): 11-3/4″ x 11″
Replaceable Gasket material: Silicone
Weight & Dimensions Outside Dimensions (LxWxH): 28”w x 22”d x 18”h
Weight: 205lbs
Compliant *CE Listing Recognized
*ISO 9001: 2008
*ISO 13485: 2003
*Manufactured in Acc. w/ Q/TIWY7-2004


Note: This oven does NOT contain a vacuum pump. External pump is required to achieve vacuum pressure

Note: This item is a freight ship item and will ship Via UPS Ground Freight. Expedited freight can only be calculated by calling customer service 331-281-0154. All orders with expedited freight through the website will not be honored and will need to be re-quoted. A valid Phone Number IS REQUIRED to ship, Otherwise UPS freight Cannot Contact you for a delivery setup window. Freight Time is 2-5 Days. West Coast 5 Days, Midwest 2 days, East Coast 3-4 days.

Specification: 1.9CF ECO Vacuum Oven and VE Series Pump Kit

Weight 230 lbs
