iSeries – PFC tablet deduster with polymer segments “C” Containment ≤OEB4
The “C” Containment model is used for toxic products, avoiding operator and production room contamination. The “C” Containment system is modularly upgradable to “HC” High Containment ≤OEB5 and washable.
Key benefits
- Patented ≤OEB4 dedusting and metal check – SMEPAC tested and ATEX certified
- Pressure monitoring with fail security valves
- 5 elevation heights from 500 mm to 1500 mm
- FDA-approved light components to handle and wash
- Ergonomic, Efficient, Robust, Reliable
- Quiet operation <69 dB(A)
- No risk of cross contamination – Easy validation
- Central HMI with OPC UA, CFR 21 Part 11 compliant
This “C” Containment version is available in 5 different heights from 500 mm to 1500mm. Our unique patented metal check system Flex Connect guarantees completely closed Contained transfer from deduster to drum without tri-clamp solution. Pressure monitoring and failsafe security valves protect the operator in case of hazardous situations. A smart system allows to introduce test samples inside the metal check head without contact between operator and product. Metal check parameters are monitored through an integration of an original software of metal check supplier inside the central machine HMI. Thanks to sophisticated engineering, this “C” Containment unit can be easily transformed into an “HC” High Containment ≤OEB5 with washable execution.
Frame pre-equipped for:
- Diverter
- Sampling
- Test sampler inserters
- Autocheck for metal checker
- IPC tester (weight, thickness, hardness and diameter)
- High containment
- Washing In Place/Washing Off Line
