CVAC 9.3 PRO Package with MAXTRAP50 – High Temp Vacuum Oven with Cold Trap

Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare

$29,417.11

Cascade Sciences’ CVAC 9.3 includes a programmable Watlow controller, a digital vacuum gauge and as a safety, a secondary independent high limit controller to help protect against temperature run-away. Ideal for industrial sized, high temp vacuum drying with a clean, quiet, oil-free vacuum pump and -50°C mechanically refrigerated cold trap.

  • 9 aluminum shelves on sliding rack for stay-in-place extension  27.5″ Wide x 23.5″D
  • Interior Dimensions of 28″ × 24″ × 24″
  • Temperature performance range of Ambient +15°C to 220°C
  • NRTL Certified.  Made in USA
  • Energize The Vacuum Pump From the Control Panel

CVAC 9.3 PRO with MAXTRAP50 Package Includes:

Vacuum Oven – Cascade CVAC9.3  220V

  • Watlow Controller Capable of 40 Step Ramp and Soak Profiles (or 4 Files with 10 Steps per File)
  • 9 aluminum shelves on sliding rack for stay-in-place extension
  • Durable, low-outgassing Viton Gasket
  • Digital Vacuum Gauge
  • Viewing Window
  • RS-485 Communication port
  • Stainless Steel Exterior Option Available (Ideal Option for Clean room Applications)
  • KF25 Port available for feedthrough connections and rear vent barb for inert gas intro
  • NRTL Certified

Vacuum Pump  – Agilent IDP15  220V

  • Powered from oven control panel
  • Cascade includes the power cord & exhaust hose at no extra charge
  • Digital hour meter for tracking service intervals
  • Hermetically sealed for longer life
  • Gas ballast allows for vacuum flexibility and higher vapor tolerance
  • Automatic thermal protection prevents overheating
  • NRTL Certified. Conforms with EN 61236-1:2006 as a Class A device, EN/IEC 61010 3rd Edition, CSA certified for US and Canada

Cold Trap – MAXTRAP50 120V

  • Temperatures to -50°C
  • UL & CSA Certified
  • Eco Refrigerants
  • Large KF-25 Inlet & Outlet
  • Stainless Steel COLDWELL Trap

SVAC 9.2

Exterior Dimensions (W × D × H): 38.1″ × 46.8″ × 63.9″ | 965 mm × 1189 mm × 16.24 mm
Interior Dimensions (W × D × H): 28″ × 24″ × 24″ | 711 mm × 610 mm × 610 mm
Volume: 9.3 Cu Ft. | 264 L
Shelf Dimensions (W × D): 27.5″ × 23.5″ | 699 mm × 597 mm
Unit Weight: 492 lbs (223 kg)
Interior Metal: 304 SST
Exterior Metal: Painted Cold Roll Steel
Operating Temperature Range: Amb +15°C to 220°C
Temperature Uniformity – +/-6% @ 150°C
Temperature Stability – Midrange: +/-0.2°C
Heat-up Time: 130 Minutes to 150°C
Controller Type: Digital
Display Resolution: 0.1°C
Power Voltage | Frequency and Current: 220-240 VAC, 50/60 Hz, 20.0 Amps
Max. HVAC Load: 11628 BTUs/hr
Safety Certifications: UL 61010-1, EN 61010-1, CSA 61010-1, CE

Specification: CVAC 9.3 PRO Package with MAXTRAP50 – High Temp Vacuum Oven with Cold Trap

Weight 1500 lbs
