BINDER BD Series Standard Avantgarde Incubators with Gravity Convection
The BINDER Series BD Avantgarde Line Standard Incubators with Gravity Convection are powerful and reliable units for many applications. These units have exceptional efficiency and temperature accuracy to meet growth and incubation requirements. The new design of the units and the homogeneous temperature distribution ensure the very best results.
$1,810.73 – $8,025.46
Options Detail
Description | Capacity | Includes | Model # |
---|---|---|---|
2 Cu. Ft. Standard Avantgarde Incubator, 230V | 2 Cu. Ft. | Gravity Convection | BD056-230V |
2 Cu. Ft. Standard Avantgarde Incubator, 120V | 2 Cu. Ft. | Gravity Convection | BD056UL-120V |
4 Cu. Ft. Standard Avantgarde Incubator, 230V | 4 Cu. Ft. | Gravity Convection | BD115-230V |
4 Cu. Ft. Standard Avantgarde Incubator, 120V | 4 Cu. Ft. | Gravity Convection | BD115UL-120V |
8.9 Cu. Ft. Standard Avantgarde Incubator, 230V | 8.9 Cu. Ft. | Gravity Convection | BD260-230V |
8.9 Cu. Ft. Standard Avantgarde Incubator, 120V | 8.9 Cu. Ft. | Gravity Convection | BD260UL-120V |
26 Cu. Ft. Standard Avantgarde Incubator, 240V | 26 Cu. Ft. | Gravity Convection | BD720UL-240V |
26 Cu. Ft. Standard Avantgarde Incubator, 230V | 26 Cu. Ft. | Gravity Convection | BD720-230V |
Description
The BINDER Series BD Avantgarde Line Standard Incubators with Gravity Convection are specially designed for gentle incubation of organisms, as well as conditioning of heat-sensitive media. The new design of the units and the homogeneous temperature distribution ensure the very best results.
Benefits:
- Excellent temporal and spatial temperature accuracy
- High process reliability
- 100 C disinfection routine
Important Characteristics:
- Temperature range: ambient temperature plus 5C to 100C
- High temperature accuracy thanks to APT.lin technology
- Gravity convection
- Controller with LCD display
- Electromechanical control of the exhaust air flap
- Inner door made of tempered safety glass
- 2 chrome-plated racks
- Units up to 115 L are stackable
- Class 3.1 integrated independent temperature safety device (DIN 12880) with visual alarm
- Ergonomic handle design
- USB port for recording data
Specification
SKU | Temperature Range | Temperature Fluctuation | Temperature Variation | Warm Up Time |
---|---|---|---|---|
9010-0323 | 100C 5C | 0.1 at 37C | 0.3 at 37C | 42 min to 37C |
9010-0324 | 100C 5C | 0.1 at 37C | 0.3 at 37C | 42 min to 37C |
9010-0325 | 100C 5C | 0.1 at 37C | 0.3 at 37C | 55 min to 37C |
9010-0326 | 100C 5C | 0.1 at 37C | 0.3 at 37C | 55 min to 37C |
9010-0329 | 100C 5C | 0.2 at 37C | 0.3 at 37C | 60 min to 37C |
9010-0330 | 100C 5C | 0.2 at 37C | 0.3 at 37C | 60 min to 37C |
9010-0332 | 100C 5C | 0.1 at 37C | 0.7 at 37C | 70 min to 37C |
9010-0331 | 100C 5C | 0.1 at 37C | 0.7 at 37C | 70 min to 37C |
Additional Info
SKU | # of Shelves | Door Recovery Time | Depth | Height | Width | Power Requirement |
---|---|---|---|---|---|---|
9010-0323 | 2 std./4 max. | 22.26 in | 24.63 in | 22.06 in | 200-230 V, 50/60 Hz | |
9010-0324 | 2 std./4 max. | 22.26 in | 24.63 in | 22.06 in | 100 – 120 V, 50/60 Hz | |
9010-0325 | 2 std./5 max. | 23.84 in | 27.78 in | 27.97 in | 200-230 V, 50/60 Hz | |
9010-0326 | 2 std./5 max. | 23.84 in | 27.78 in | 27.97 in | 100 – 120 V, 50/60 Hz | |
9010-0329 | 2 std./8 max. | 29.94 in | 34.67 in | 31.91 in | 200-230 V, 50/60 Hz | |
9010-0330 | 2 std./8 max. | 29.94 in | 34.67 in | 31.91 in | 100 – 120 V, 50/60 Hz | |
9010-0332 | 2 std./16 max. | 34.28 in | 62.6 in | 45.9 in | 240 V, 50/60 Hz | |
9010-0331 | 2 std./16 max. | 34.28 in | 62.6 in | 45.9 in | 230 V, 50/60 Hz |
