Sale!

Ai-DigiVac Concerto 4-Channel Vacuum & Pressure Controller

Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare

$4,632.50$5,232.50

SKU: Concerto-A4 Category: Brand:

Another innovation from Across International and DigiVac that has just won the 2020 PITTCON TODAY Excellent Award, Silver, for Excellence in Instrumentation, the Concerto 4-channcel rotary evaporator controller. Control Your evaporation process like a symphony! Control up to 4 rotary evaporators or chambers with a single vacuum pump. Fine tune your evaporation process with Concerto!



Ai & Digivac Concerto Multi-Channel Vacuum Controller is
PittCon 2020 Silver Innovation Award Winner


SIMPLIFY YOUR LAB & CONTROL MORE WITH LESS

  • Up to 4 chamber control with only 1 high-end vacuum pump for rotary evaporators up to 100 Liters and Falling Film Systems
  • Fine control of target vapor pressure for more precise compound separation through distillation
  • Enables using reliable and long lasting rotary vane oil pumps & dry scroll pumps in applications where diaphragm pumps were previously required

Keeps vacuum pumps near their base pressure resulting in greater longevity

PRECISION CONTROL & INTUITIVE DESIGN

  • Ease of use through precise automated control with programmable recipes and graphing of vacuum levels
  • Innovative valve control performs both proportional throttle and bleed vacuum control (vent to atmosphere)
  • The integrated bleed design allows you to quickly vent to atmosphere to stop bumping during processing
  • Numerical readings right on the LCD screen and one touch start, stop and release buttons


FEATURES

  • Silver Innovation Award Winner for Instrumentation at PittCon 2020!
  • GO BIG OR GO HOME & MAXIMIZE THROUGHPUT: Largest flow paths available to insure maximum flow for faster evaporation
  • The rotary evaporator controller is particularly useful when you are looking to maintain pressure at a certain level as needed for botanical processing and rotary evaporation. Mounting is bench top.
  • Simplify your lab & control more with less
  • Up to 4 chamber control with only 1 high-end vacuum pump for rotary evaporators up to 100 Liters and Falling Film Systems
  • Fine control of target vapor pressure for more precise compound separation through distillation
  • Enables using reliable and long lasting rotary vane oil pumps and dry scroll pumps in applications where diaphragm
  • pumps were previously required
  • Keeps vacuum pumps near their base pressure resulting in greater longevity
  • Go big or go home and maximize throughput
  • Largest flow paths available to insure maximum flow for faster evaporation
  • Precision control and intuitive design
  • Ease of use through precise automated control with programmable recipes and graphing of vacuum levels
  • Innovative valve control performs both proportional throttle and bleed vacuum control (vent to atmosphere)
  • The integrated bleed design allows you to quickly vent to atmosphere to stop bumping during processing
  • Numerical readings right on the LCD screen and one touch start, stop and release buttons
  • Made in the USA

Concerto – Interface Basic

Concerto – Setpoints Overview

Concerto – Setting Setpoints

Concerto – Recipes Overview

Concerto – Setup New Recipes

Concerto – Calibration
